COMMON PARTS - CYLINDER BEARING HOUSINGS
ITEM RANSOMES
PART NO
8513 GSF3702SZ
9011 MBE1884C
9011 2201002
* MBG1696
9012 MBC7671
9013 H083023
9014 450412
9015 450325
9016 A299301
9017 451153
9018 MBE2231
9019 A230013
9020 A209044
9021 A230019
9022 MBE2374B
9022 2203038
9023 A292083
9024 A151010
9024 A159401
9025 450379
9025 450379
9026 A110406
9026 2203039
9027 A199302
9028 A221327
9028 A221031
9029 MBE4676
9030 450378
9031 MBE2982B
* MBG1694
9032 MBC7671
9033 H083023
9034 450412
9035 450325
9036 A299301
9037 451153
DESCRIPTION
GB
Label (+<->-)
Bearing Housing RH
Bearing Housing RH
Bearing Housing LH
Shoulder pin
Disc Spring
S.L.Washer 10mm
Nut M10
Lubricator
Screw No.12 x 13
Ring Carrier
Seal Ring
Taper Roller Bearing
Rotary Shaft Seal
Stud
Stud, 10mm / 8mm
Disc Spring
S.L.Washer 10mm
Washer , 0.328
Stiffnut M10
Stiffnut M10
Screw M10 x 30
Stud, 10mm / 8mm
Helicoil Insert
O Ring
O Ring
Spacer
Nut, M8 Nyloc
Bearing Housing LH
Bearing Housing RH
Shoulder Pin
Disc Spring
S.L.Washer 10mm
Nut M10
Lubricator
Screw No.12 x 13
* Not Illustrated
QTY REMARKS
2
1 (Fairway 300)
1 (T-Plex 185 RHD, T-Plex 285 &
Fairway 250, 305, 405)
1 (T-Plex 285 LHD, T-Plex 185 LHD)
1
1
1
1
1
1
1
1
1
1
1 (T-Plex 185, T-Plex 285 &
Fairway 305, 405)
1 (Fairway 250)
1
2 (T-Plex 185, T-Plex 285 &
Fairway 305, 405)
2 (Fairway 250)
1 (Fairway 250)
1 (T-Plex 185, T-Plex 285 &
Fairway 305, 405)
1 (T-Plex 185, T-Plex 285 &
Fairway 305, 405)
1 (Fairway 250)
3
1 (Fairway 300)
1 (T-Plex 185, T-Plex 285 &
Fairway 250, 305, 405)
1
1 (Fairway 250)
1 (T-Plex 185, T-Plex 285 RHD &
Fairway 300, 305, 405)
1 (T-Plex 285 LHD, T-Plex 185 LHD)
1
1
1
1
1
1
LIST OF PARTS
