Textron RANSOMES Sicherheits Und Bedienungs Anleitung / Ersatzteilliste Seite 119

CUTTING CYLINDER & FRONT PLAIN ROLL (FLOATING HEAD)
T-Plex 185 series US & T-Plex 285
ITEM RANSOMES
PART NO
LMSE115
3011 MBF0486
3012 MBG1210
3013 MBF0001
3014 A230013
3015 A291115
3016 A205929
3017 MBE2429
3018 A220254
3019 451982
3020 MBE2430
3021 A221137
3022 A299301
3023 MBE2431B
3024 450334
3026 A230021
3028 MBF0002
3035 MBE3984
3036 452565
3037 450378
3038 450390
3045 MBE3985
3046 452565
3047 450378
3048 450390
3055 MBE3982
3056 MBE4001
3057 452464
3065 A906732
3066 450323
9011 MBF0483
* MBF0671
9011 MBF0484
* MBF0677
DESCRIPTION
GB
Plain Roll Assy.
• Roll Tube
• Spindle
• Ring Carrier
• Seal Ring
• Compression Spring
• Taper Roller Bearing
• Bearing Housing
• Rotary Lip Seal
• Circlip
• Seal Journal
• O Ring
• Lubricator
• Shield
• Thin Nut M16
• Seal Ring
• Washer
Housing Front LH
Bolt M8 x 30
Stiffnut M8
Washer 8mm
Housing Front RH
Bolt M8 x 30
Stiffnut M8
Washer 8mm
Carriage Front
Carriage Nut
Screw M8 x 16
Scraper cable
Nut M6
Cutting Cylinder 7k RHD
Cutting Cylinder 7k LHD
Cutting Cylinder 11k RHD
Cutting Cylinder 11k LHD
* Not Illustrated
QTY REMARKS
1
1
1
2
1
2
2
2
2
2
2
4
2
2
4
1
2
1
1
1
1
1
1
1
1
2
4
2
1
2
1
1
1
1
LIST OF PARTS
69
