COMMON PARTS - MAIN FRAME & MOUNTING
ITEM
RANSOMES
PART NO
2011
MBE1808H
2011
MBF0485
2011
MBF0817A
2012
A128053
2013
GSF2240KT
2014
450724
2015
AF09010
2016
450390
2017
450378
2018*
MBF0715
2019*
A139917
2021
MBE1927B
2021
MBG1209
2021
MBG2043
2022
A119130
2022
A110204
2023
450410
2024
450389
2030
MBE1845D
2030
2206042
2030
MBF0501
2030
2206004
2031*
GSF3014LF
2032
MBE3302
2032
2203001
2033
A100413
2033
450034
2034
450379
2035
450391
2036
A299316
2037
450389
2038
GSF3014LF
2040
A292083
2051
MBE1941
2052
450214
2053
450412
8511
A903644
8512
A903400
8514
MBE3628
8515*
A149605
DESCRIPTION
GB
Main Frame
Main Frame
Main Frame
Screw No.12 x 13
Spring
Screw M8 x 25
Spacer
Washer 8mm
Stiffnut M8
Stop Bar
Star Ring, 8mm
Top Cover
Top Cover
Top Cover
Screw M6 x 16
Screw M6 x 20
S.L.Washer 6mm
Washer 6mm
Yoke
Yoke
Yoke
Yoke
Bush
Pivot Bush
Pivot Bush
Bolt M10 x 65
Bolt M10 x 60
Stiffnut M10
S.L.Washer 10mm
Lubricator 45°
Washer 6mm
Bush
Disc Spring
Top Plate
Screw M10 x 25
S.L.Washer 10mm
Label - RANSOMES
Label - Hands & Feet
Name Plate
Rivet 1/8 x 5/16
* Not Illustrated
QTY
REMARKS
1
(Fairway 300, 305, 405, T-Plex 185
series RE, ST, UL)
1
(T-Plex 285, T-Plex 185 series US)
1
(Fairway 250)
2
2
2
2
2
2
1
(Fairway 250)
2
(Fairway 250)
1
(Fairway 300 & T-Plex 185 series
RE, ST, UL)
1
(T-Plex 285, T-Plex 185 series US)
1
(Fairway 250)
4
(Fairway 250, 300)
4
(T-Plex 185, T-Plex 285 &
Fairway 305, 405)
4
4
1
(Fairway 300 & T-Plex 185 series
RE, ST, UL))
1
(Fairway 305, 405)
1
(T-Plex 285, T-Plex 185 series US)
1
(Fairway 250)
2
(Fairway 250)
2
(Fairway 300,T-Plex 185 &
T-Plex 285)
2
(Fairway 250, 305, 405)
2
(Fairway 300
2
(Fairway 250, 305, 405)
2
2
1
1
2
2
1
(Fairway 300, 250, 305, 405)
4
4
1
1
1
(Used on T-Plex only)
2
(Used on T-Plex only)
LIST OF PARTS
& T-Plex 185)
39
