GB
MAINTENANCE
Read the Safety Instructions
Check all nuts and bolts every 75 hours
Lubrication of Direct Drive Hydraulic Motor
(Every 400 hours)
Lower all cutting units onto level ground. Before leaving
the driving position, stop the engine and make sure all
moving parts are stationary. Apply brakes and
disengage all drives. remove the starter key. The direct
drive hydraulic motor can be removed from the cutting
unit by removing the two screws and washers holding
the motor to the bearing housing. Carefully withdraw
the motor from the bearing housing, it is important not
to contaminate the motor shaft or internal splines of
the cutting cylinder. If for any reason they are
contaminated, they should be cleaned by degreasing.
Liberally lubricate the motor and cylinder splines with
Shell S7222 grease (Textron Part no. MBE3927)
before reassembling.
GB-F-NL-12
