GRASSBOX AND FIXINGS, T-Plex 185
series UL
ITEM
RANSOMES
PART NO
LMAB484
1
BAM6160
2
W106172
3
MBC1629
4
MBC8114A
5
MBC8940
6
MBC1617
7
MBC1618
8
MBC1630
9
BAM2245
10
BAM2288
11
GSF2093AD
12
GSF2093CD
13
GSF2091CK
14
A139912
15
MBF1318A
16
MBF1321A
17
MBF1337
18
MBF1336
19
MBF1341
20
MBF1343
21
A139322
23*
450390
24*
A149623
25*
A149622
26*
GSF2150C
DESCRIPTION
GB
GRASSBOX KIT
GRASS BOX WITH SCREEN FR.
STIFFENER
BACKING PLATE
STOP PLATE
BACKING PLATE
CORNER PLATE R.H.
CORNER PLATE L.H.
BACKING PLATE
STIFFENER
BRACE
SCREW, 1/4" UNC X 3/4" LONG
SCREW, 5/16" UNC X 3/4" LONG
BOLT 5/16"UNC X 2" HEX HEAD
NUT, 1/4 UNC
GRASSBOX BRKT LH
GRASSBOX BRKT RH
GRASSBOX MOUNT RH
GRASSBOX MOUNT LH
HOOK-FRONT RH
HOOK-FRONT LH
NUT, 5/16 UNC
WASHER, M8
RIVET 3/16"
RIVET 1/4"
WASHER 1/4"
* Not Illustrated
QTY
REMARKS
3
2
12
6
30
3
3
6
1
6
18
4
4
18
2
2
1
1
3
3
4
4
30
42
42
LIST OF PARTS
75
