Textron RANSOMES Sicherheits Und Bedienungs Anleitung / Ersatzteilliste Seite 95

COMMON PARTS - REAR ROLL - T-Plex 285, T-Plex 185 series US
ITEM RANSOMES
PART NO
3011 MBF0486
3012 MBG1210
3013 MBF0001
3014 A230013
3015 A291115
3016 A205929
3017 MBE2429
3018 A220254
3019 451982
3020 MBE2430
MBE1372
450326
A221910
3021 A221137
3022 A299301
3023 MBE2431B
3024 450334
3026 A230021
3028 MBF0002
3035 MBE3986
3036 A102306
3037 A133208
3038 A150008
3055 MBE3982
3056 MBE4001
3057 A114395
3058 MBE4017
3065* A906732
3066* A130006
DESCRIPTION
GB
Plain Roll Assy.
• Roller Tube
• Spindle
• Ring Carrier
• Seal Ring
• Compression Spring
• Taper Roller Bearing
• Bearing Housing
• Rotary Lip Seal
• Circlip
• Seal Journal
• Washer
• Nut M12
• O Ring
• O Ring
• Lubricator
• Shield
• Nut M16 thin
• Seal Ring
• Washer
Housing - Rear
Bolt M8 x 30
Stiffnut M8
Washer 8mm
Carriage - Rear
Carriage Nut
Screw M8 x 16
Carriage Nut
Scraper Cable
Nut M6
* Not Illustrated
QTY REMARKS
1
1
1
2
1
2
2
2
2
2
2
2
2
4
4
2
2
4
1
2
2
4
4
4
2
2
2
2
1
2
LIST OF PARTS
