COMMON PARTS - REAR ROLL - Fairway 300, 305, 405,
T-Plex 185 series UL
ITEM RANSOMES
PART NO
LMSE079
3011 MBE1761D
3012 MBE1752C
3013 MBF0001
3014 A230013
3015 A291115
3016 A205929
3017 MBE2429
3018 A220254
3019 451982
3020 MBE2430
3021 A221137
3022 A299301
3023 MBE2431B
3024 450334
3026 A230021
3028 MBF0002
3035 MBE3986
3036 452565
3037 450378
3038 450390
3055 MBE3982A
3056 MBE4001
3057 452464
3058 MBE4017
3065* A906704
3066* 450323
DESCRIPTION
GB
Plain Roll Assy.
• Roller Tube
• Spindle
• Ring Carrier
• Seal Ring
• Compression Spring
• Taper Roller Bearing
• Bearing Housing
• Rotary Lip Seal
• Circlip
• Seal Journal
• O Ring
• Lubricator
• Shield
• Thin Nut M16
• Seal Ring
• Washer
Housing - Rear
Bolt M8 x 30
Stiffnut M8
Washer 8mm
Carriage - Rear
Carriage Nut
Screw M8 x 16
Carriage Nut
Scraper Cable
Nut M6
* Not Illustrated
QTY REMARKS
1
1
1
2
1
2
2
2
2
2
2
4
2
2
4
1
2
2
4
4
4
2
2
2
2
1
2
LIST OF PARTS
43
