GRASSBOX AND FIXINGS, T-Plex 185
series ST, RE
ITEM
RANSOMES
PART NO
LMAA349
1
MBF0587
2
450190
3
450411
4
MBG1158
5
MBG1079
6
W2208014
7
W2208015
8
2203029
9
2202019
10
450865
11
451450
12
450193
13
MBF0606
14
MBF0607
15
MBG1162
16
450215
17
450412
18
GSF2151AR
19
MBF0588
20
MBF0462
21
2208020
22
32418-03
23
GSF2152A
24
GSF2093AD
25
A139912
26
MBF0464
DESCRIPTION
GB
GRASSBOX KIT
RAIL W.A.
SCREW, M8 X 16
S.L.WASHER, 8 MM
HOOK YOKE
HOOK YOKE
SPRING LH
SPRING RH
BUSHING - GRASS-BOX
LATCH-CATCHER
SCREW, M8 X 20
PIN, 6 X 20
SCREW, M8 X 30
PLATE CATCH R.H.
PLATE CATCHER L.H.
PIN CATCHER
SCREW, M10 X 30
S.L.WASHER, 10 MM
PLAIN WASHER
GRASSBOX MOUNT RH
GRASSBOX BRKT LH
GRASSBOX T-PLEX
HANDLE (GRASSBOX)
PLAIN WASHER
SCREW, 1/4" UNC X 3/4" LONG
NUT, 1/4 UNC
GRASSBOX BRKT RH
* Not Illustrated
QTY
REMARKS
1
6
2
2
2
2
2
4
4
4
12
4
2
2
4
4
4
4
1
1
3
3
36
30
30
1
LIST OF PARTS
77
