Textron RANSOMES Sicherheits Und Bedienungs Anleitung / Ersatzteilliste Seite 111

CUTTING CYLINDER & FRONT GROOVED ROLL 30" Unit
T-Plex 285 & 185 series US
ITEM RANSOMES
PART NO
LMSE114
3011 MBG1901
3012 MBG1210
3013 MBF0001
3014 A230013
3015 A291115
3016 A205929
3017 MBE2429
3018 A220254
3019 A170052
3020 MBE2430
3021 A221137
3022 A299301
3023 MBE2431
3024 A130116
3026 A230021
3028 MBF0002
3035 MBE3984
3036 A102306
3037 A133208
3038 A150008
3045 MBE3985
3046 A12306
3047 A133208
3048 A150008
3055 MBE3982
3056 MBE4001
3057 A114395
3065 MBG1983
3066 MBF0499
3067 A110296
3068 A151006
3069 MBE4333A
3070 MBE4334A
3071 A100207
3072 A100208
3073 A133206
3074 A150006
9011 MBF0483
* MBF0671
DESCRIPTION
GB
Grooved Roll Assy 30".
Roll Tube
Spindle
Ring Carrier
Seal Ring
Compression Spring
Taper Roller Bearing
Bearing Housing
Rotary Lip Seal
Circlip
Seal Journal
O Ring
Lubricator
Shield
Thin Nut M16
Seal Ring
Washer
Housing Front LH
Bolt M8 x 30
Stiffnut M8
Washer 8mm
Housing Front RH
Bolt M8 x 30
Stiffnut M8
Washer 8mm
Carriage Front
Carriage Nut
Screw M8 x 16
Scraper
Carrier W/Assy
Screw M6 x 16
Dia 6 Lock Washer
LH Scraper Bracket
RH Scraper Bracket
Bolt M6 x 35
Bolt M6 x 40
M6 Staytite Nut
Washer 6mm
Cutting Cylinder 7k RHD
Cutting Cylinder 7k LHD
* Not Illustrated
QTY REMARKS
1
1
1
2
1
2
2
2
2
2
2
4
2
2
4
1
2
1
1
1
1
1
1
1
1
2
4
2
1
1
4
4
1
1
2
2
4
12
1
1
LIST OF PARTS
61
