SPECIFICATION
CONSTRUCTION
Heavy duty welded pressed steel construction
CYLINDER:
Diameter:
Width of cut:
Number of knives:
Height of cut:
CUTTING CYLINDER TO BOTTOM BLOCK
ADJUSTMENT
Self locking notched hand micro adjusters. Each
notch giving 0.04mm (0.0015in) of movement.
HEIGHT OF CUT ADJUSTMENT
Front roll: Threaded roll carriage & locknuts.
Rear roll: Coarse adjustment: Three position
Fine adjustment:
REAR ROLL
Full width 75mm (3in) diameter plain roll running on
taper roller bearings with shaft seals and lubricators.
FRONT ROLL
Full width 75mm (3in) diameter grooved roll running
on taper roller bearings with shaft seals and
lubricators.
or
Full width 75mm (3in) diameter plain roll running on
taper roller bearings with shaft seals and lubricators.
BOTTOM BLOCK & BLADE
Blade replaceable, mounted onto welded steel
constructed bottom block.
TRANSMISSION
By hydraulic motor through cardan shaft to cutting
cylinder.
GB
165mm (6 1/2in)
660mm (26in)
7 and 11
6mm - 38mm
(1/4in - 1 1/2in)
housing mounting.
Threaded roll
carriage & locknuts
