CUTTING CYLINDER & FRONT GROOVED ROLL (FLOATING HEAD)
22" UNIT
Fairway 250
ITEM
RANSOMES
PART NO
LMSE120
3011
MBG2051
3012
MBG2045
3013
MBF0001
3014
A230013
3015
A291115
3016
A205929
3017
MBE2429
3018
A220254
3019
451982
3020
MBE2430
3021
A221137
3022
A299301
3023
MBE2431B
3024
450334
3026
A230021
3028
MBF0002
3035
MBE3984
3036
452565
3037
450378
3038
450390
3045
MBE3985
3046
452565
3047
450378
3048
450390
3055
MBE3982A
3056
MBE4001
3057
452464
3065
MBG2052
3066
MBF0823
3067
450170
3068
450410
3069
MBE4333A
3070
MBE4334A
3071
450002
3072
450003
3073
450377
3074
450389
9011
MBF0821A
9011*
MBF0822A
DESCRIPTION
GB
Grooved Roll Assy 22".
Roll Tube
Spindle
Ring Carrier
Seal Ring
Compression Spring
Taper Roller Bearing
Bearing Housing
Rotary Lip Seal
Circlip
Seal Journal
O Ring
Lubricator
Shield
Thin Nut M16
Seal Ring
Washer
Housing Front LH
Bolt M8 x 30
Stiffnut M8
Washer 8mm
Housing Front RH
Bolt M8 x 30
Stiffnut M8
Washer 8mm
Carriage Front
Carriage Nut
Screw M8 x 16
Scraper
Carrier W/Assy
Screw M6 x 16
Dia 6 Lock Washer
LH Scraper Bracket
RH Scraper Bracket
Bolt M6 x 35
Bolt M6 x 40
M6 Staytite Nut
Washer 6mm
Cutting Cylinder 7K
Cutting Cylinder 11K
* Not Illustrated
QTY
REMARKS
1
1
1
2
1
2
2
2
2
2
2
4
2
2
4
1
2
1
1
1
1
1
1
1
1
2
4
2
1
1
4
4
1
1
2
2
4
12
1
1
LIST OF PARTS
59
