Textron RANSOMES Sicherheits Und Bedienungs Anleitung / Ersatzteilliste Seite 115

CUTTING CYLINDER & SKIDS (FIXED HEAD)
T-Plex 185 & T-Plex 285
ITEM RANSOMES
PART NO
9127 MBF0469
9127 MBF0482
* MBF0670
9130 MBE0092
9131 MBE0093
9132 MBF0438
9133 MBF0437
9134 MBG1067
9135 MBG1068
9136 A110204
9137 A150006
9138 A130006
9139 MBF0411
9140 A110305
9141 A150008
9142 A133208
9143 MBG0958
6250* MBG0958
6251* MBF0411
6252* 450378
6253* 450411
6255* A906071
6261* LMSD933A
DESCRIPTION
GB
Cutting Cylinder 5K
Cutting Cylinder 5K RHD
Cutting Cylinder 5K LHD
Fixed Head Skids & Restraint
Front Skid RH
Front Skid LH
Strut RH
Strut LH
Plate
Collar
Screw M6 x 20
Washer 6mm
Nut M6
Shoulder Bolt
Screw M8 x 25
Washer 8mm
Nut M8
Anchor Plate
Floating Head Restraint
Anchor Plate
Shoulder Bolt
Nut-hex M8 Nyloc
Lockwshr-m8 X 12.75 X 2
Cable
Hoc Guage.
* Not Illustrated
QTY REMARKS
1 T-Plex 185
1 T-Plex 285
1 T-Plex 285
1
1
1
1
2
2
4
4
4
2
2
2
2
2
6
12
6
6
6
1
LIST OF PARTS
65
