Basic i.LINK operations

■ Assigning i.LINK components
When an i.LINK component is connected, this unit
automatically recognizes the connection and registers up
to 16 i.LINK components. Assigning an i.LINK
component to a specific input allows you to select video
and audio input signals from that component received via
the i.LINK connection for simultaneous playback.
Turn on the power of this unit and the connected
i.LINK component.
The i.LINK component is automatically recognized and
registered in the following order.
DVD → DTV → CBL/SAT → VCR1 → DVR/VCR2 →
V-AUX → PHONO → CD → CD-R → MD/TAPE
"LINK CHECK" flashes on the front panel display during
this procedure.
Notes
• If you want to change the input assignment of a registered
i.LINK component, use Input Assign in the GUI menu
(see page 94) or INPUT ASSIGN in the front panel display
system options menu (see page 91).
• Only one i.LINK component is assigned to each input and
inputs that are already assigned are skipped.
• If i.LINK components are assigned to all the inputs available,
no more i.LINK components can be assigned, and audio signals
input from these i.LINK components cannot be played back on
this unit.
• You can display the name of the input assigned to the selected
i.LINK component by using the Assign feature in the
Information menu (see page 94).
■ Listening to playback from i.LINK
components
If an i.LINK component has been assigned to a specific
input, perform the following steps to listen to playback
from the registered i.LINK component.
1
Rotate the INPUT selector to select the input
assigned to the i.LINK component.
2
Press AUDIO SELECT repeatedly to set
"AUTO" or "i.LINK" as the input mode.
V-AUX DVR/VCR2 VCR 1 CBL/SAT DTV
SP
A
A.SEL:AUTO
V-AUX DVR/VCR2 VCR 1 CBL/SAT DTV
SP
A
A.SEL:i.LINK
3
Start playback on the connected i.LINK
component.
DVD MD/TAPE CD-R CD TUNER PHONO
dB
VOLUME
L R
or
DVD MD/TAPE CD-R CD TUNER PHONO
dB
VOLUME
L R
Notes
• You can turn on/off automatic playback when an i.LINK
component is selected using the INPUT selector or to select
whether you want the input to switch automatically when an
input stream from a connected i.LINK component is detected
(see page 94).
• Audio signals input at the i.LINK jacks are digitally output only
when AUDIO SELECT is set to either AUTO or i.LINK as the
input mode and REC OUT/ZONE 2 on the front panel is set to
SOURCE/REMOTE.
Changing i.LINK Select
parameters
Use this menu to display information about registered
i.LINK components, delete any unused registered
components, or customize the operation and playback
settings to be used when this unit is connected to an
i.LINK component.
1
Switch on this unit and video monitor.
2
Set AMP/SOURCE/TV to AMP, then press
TOP on the remote control.
The top display appears.
AMP
SOURCE
TV
Stereo/Surround
Input Select
Manual Setup
Auto Setup
System Memory
3
Press k / n repeatedly to select i.LINK Select.
HDMI
i.LINK Select
Stereo/Surround
Input Select
4
Press ENTER or h, then press k / n
repeatedly to change the setting of the item
you want to adjust.
5
Press EXIT.
USING i.LINK
TOP
TITLE
Sound
Basic
Option
Information
Information
Select
Auto Play
93
