PLAYBACK
■ To listen with headphones
("SILENT CINEMA")
"SILENT CINEMA" allows you to enjoy multi-channel
music or movie sound, including Dolby Digital and DTS
surround, through ordinary headphones. "SILENT
CINEMA" activates automatically whenever you connect
headphones to the PHONES jack while listening to
CINEMA DSP or HiFi DSP sound field programs. When
activated, the "SILENT CINEMA" indicator lights up in
the front panel display.
Notes
• This unit will not be set to
MULTI CH INPUT is selected as the input source.
" "
• SILENT CINEMA is not effective when PURE DIRECT or a
2ch Stereo program is selected, or in STRAIGHT mode.
■ Selecting the MULTI CH INPUT
Press MULTI CH INPUT so that "MULTI CH INPUT"
appears in the front panel display and video monitor.
MULTI CH
INPUT
Front panel
Note
When "MULTI CH INPUT" is shown on the front panel display
and/or the video monitor, no other source can be played. To select
another input source with the INPUT selector on the front panel
(or one of the input selector buttons on the remote control), press
MULTI CH INPUT to turn off "MULTI CH INPUT" from the
front panel display and the video monitor.
36
" "
SILENT CINEMA when
MULTI CH IN
or
Remote control
■ Enjoying multi-channel software in
6.1/7.1 channel surround
If you connected one or two surround back speakers, use
this feature to enjoy 6.1/7.1-channel playback for
multi-channel sources using the Dolby Pro Logic x,
Dolby Digital EX or DTS-ES decoders.
Set AMP/SOURCE/TV to AMP, then press EXTD
SUR. on the remote control to switch between 5.1
and 6.1/7.1 channel playback.
EXTD SUR.
To select a decoder, press l / h repeatedly
when PL xMovie (etc.) is displayed.
Auto (AUTO)
When a signal (flag) that can be recognized by the unit is
input, the unit selects the optimum decoder for playing
back the signal in 6.1/7.1 channels.
If the unit cannot recognize the flag or no flag is present in
the input signal, it cannot automatically be played in
6.1/7.1 channels.
Decoders (select with l / h)
You can select from the following modes depending on
the format of the software you are playing.
PL xMovie I I
For playing back Dolby Digital or DTS signals in 7.1
channels using the Pro Logic x movie decoder.
PL xMusic I I
For playing back Dolby Digital or DTS signals in 6.1/7.1
channels using the Pro Logic x music decoder.
EX/ES
For playing back Dolby Digital signals in 6.1/7.1 channels
using the Dolby Digital EX decoder.
DTS signals are played back in 6.1/7.1 channels using the
DTS-ES decoder.
EX
For playing back Dolby Digital or DTS signals in 6.1/7.1
channels using the Dolby Digital EX decoder.
Off (OFF)
For playing back Dolby Digital or DTS signals in 5.1
channels.
y
When Surround Back is set to "Large x1" or "Small x1"
(see page 64), the surround back channel will output from the left
SURROUND BACK speaker terminals.
