CONTROLS AND FUNCTIONS
0 MEMORY 1/2
Use to recall favorite sound field programs, YPAO
settings or additional preset stations (see page 70).
A MACRO ON/OFF
Turns the macro function on and off.
B MACRO
Use to program a series of operations for control by a
single button (see page 77).
C STANDBY
Sets this unit in the standby mode.
D SYSTEM POWER
Turns on the power of this unit.
E AUDIO SELECT
Toggles the priority for the type of audio input jack
(AUTO, i.LINK, HDMI, COAX/OPT, ANALOG) when
one component is connected to two or more input jacks on
this unit (see page 40).
F SLEEP
Sets the sleep timer.
G MULTI CH IN
Selects MULTI CH INPUT when using an external
decoder (etc.).
H SELECT k / n
Selects another component that you can control
independently of the input component selected with the
input selector buttons.
I VOL +/–
Increases or decreases the volume level.
J AMP/SOURCE/TV
Selects the component you want to control with the
remote control.
AMP: Set to this position to operate this unit.
SOURCE: Set to this position to operate the component
selected with an input selector button.
TV: Set to this position to operate the television.
To set the remote control codes for components, see
page 72.
K MUTE
Mutes the sound. Press again to restore the audio output to
the previous volume level.
L PURE DIRECT
Turns on or off PURE DIRECT mode (see page 38).
M EXIT
Use to exit the graphical user interface (GUI) mode when
AMP/SOURCE/TV is set to AMP.
8
N NIGHT
Turns on or off the night listening modes (see page 38).
O DISPLAY
Use to enter into the front panel display menu mode when
AMP/SOURCE/TV is set to AMP.
P STRAIGHT/EFFECT
Switches the sound fields off or on. When STRAIGHT is
selected, input signals (2-channel or multi-channel) are
output directly from their respective speakers without
effect processing.
Q SPEAKERS A/B
Use to turn on or off the set of front speakers connected to
the A and/or B terminals on the rear panel when
AMP/SOURCE/TV is set to AMP, then the corresponding
button is pressed each time.
R RE-NAME
Used to change the input source name in the display
window (see page 76).
S CLEAR
Used to clear functions acquired when using the learn,
macro and rename features, or setting remote control
codes (see page 79).
T LEARN
Used to set up the remote control code or program
functions from other remote controls (see page 74).
U Radio Data System tuning buttons
(U.K. and Europe models only)
These buttons are operative when the unit is in the tuner
mode.
FREQ/TEXT
Press this button when the unit is receiving a Radio Data
System station to cycle the display between the PS mode,
PTY mode, RT mode, CT mode (if the station offers those
Radio Data System data services) and/or the frequency
display (see page 45).
PTY SEEK MODE
Press this button to set the unit to the PTY SEEK mode
(see page 46).
PTY SEEK START
Press this button to begin searching for a station after the
desired program type has been selected in the PTY SEEK
mode (see page 46).
EON
Press this button to select a radio program type (NEWS,
INFO, AFFAIRS, SPORT) to tune in automatically (see
page 47).
