Gemü SUPM SUMONDO Betriebsanleitung Seite 53

Inhaltsverzeichnis

Werbung

Verfügbare Sprachen

Verfügbare Sprachen

5
6
7
www.gemu-group.com
Anzugsdreh-
moment: 4 Nm
Tightening tor-
que: 4 Nm
Antrieb schlie-
ßen
Close the ac-
tuator
Rastbolzen
entriegeln
Unlock the in-
90°
dexing plunger
8
Demontage SUMONDO SUPM / Disassembling the
SUMONDO SUPM
Steuerfunktion 1 / Control function 1
1
2
53 / 56
Anhang / Appendix
Ventil 5x auf-
und zufahren
Open and clo-
se the valve fi-
ve times
Antrieb öffnen
Open the ac-
tuator
Rastbolzen
leicht heraus-
ziehen, drehen
und wieder
einrasten las-
sen.
Pull out the in-
90°
dexing plunger
slightly, turn it
and let it enga-
ge again.
GEMÜ SUPM
