6 Technical data
6.1 Medium
Working medium:
Control medium:
6.2 Temperature
Media temperature:
Ambient temperature:
Control medium
temperature:
Storage temperature:
6.3 Pressure
Operating pressure:
Control pressure:
Filling volume:
6.3.1 Kv values
NPS
MG
Connection
1)
Code
1/4"
B
HB
3/8"
B
HB
1/2"
B
HB
1/2"
C
HB
3/4"
C
HB
CA
1"
C
HB
CA
3/4"
D
CA, HB
www.gemu-group.com
Corrosive, inert, liquid media which have no negative impact on the
physical and chemical properties of the body and diaphragm material.
Oil concentration Class 4
(max. oil concentration 25 mg/m³)
5 to 40 °C
0 to 40 °C
max. 40°C
0 to 40 °C
0 to 4,9 bar
Control function 1 = 4.5 - 7.0 bar
Control function 2 = 3.5 - 5.5 bar
Control function 1 = 0.03 dm³
Control function 2 = 0.07 dm³
Body con-
figuration
2)
Code
D
D
T
R
D
T
R
D
D
T
D
T
D
T
D
T
D
Kv value
0.47
1.08
1.03
1.02
1.59
1.47
1.44
2.17
3.29
2.15
3.29
2.15
4.55
3.81
4.55
3.81
9.21
33 / 56
6 Technical data
Cv value
0.54
1.25
1.19
1.18
1.84
1.70
1.67
2.51
3.81
2.49
3.81
2.49
5.27
4.41
5.27
4.41
10.66
GEMÜ SUPM
