7 Dimensions

7.1 Actuator dimensions

1/4" (DN 8), 1/2" (DN 15)
A
A1
A2
A3
A4
G
□LxB
øC
øD
□lxb
M
Dimensions in mm, MG = diaphragm size
www.gemu-group.com
MG B
153.2
148.1
110.7
34
123
G1/4
120
6.5
61
100
M16x1
□ l x b
MG C
3/4" (DN 20), 1" (DN 25)
166
146.4
112
34
123
G1/4
120
6.5
61
100
M16x1
35 / 56
7 Dimensions
MG D
3/4" (DN 20), 1" (DN 25)
176.7
150.8
110.6
34
123
G1/4
120
6.5
61
100
M16x1
