7.2.2 2/2-way body (code D)
ØD
Con-
nection
1/4"
1)
Code
(DN 8)
L CA -
H1 -
H2 -
øD -
L HB 80.6
H1 33.3
H2 22.3
øD 64
Dimensions in mm, MG = diaphragm size
1) Connection
Code CA: Clamp connection similar to ASME-BPE
Code HB: Hose barb
