Anhang / Appendix
7
8
Steuerfunktion 2 / Control function 2
1
GEMÜ SUPM
Rastbolzen
entriegeln
90°
Unlock the in-
dexing plunger
Ventil 5x auf-
und zufahren
Open and clo-
se the valve fi-
ve times
Antrieb öffnen
Open the ac-
tuator
2
3
4
52 / 56
Rastbolzen
leicht heraus-
ziehen, drehen
und wieder
einrasten las-
sen.
Pull out the in-
dexing plunger
90°
slightly, turn it
and let it enga-
ge again.
