5 Order data

The order data provide an overview of standard configurations.
Please check the availability before ordering. Other configurations available on request.

5.1 Pneumatic actuator SUPM

Order codes

1 Type
Pneumatically operated actuator
metal version
2 Diaphragm size
Diaphragm size B
Diaphragm size C
Diaphragm size D
Order example SUPM
Order option
1 Type
2 Diaphragm size
3 Diaphragm mounting
4 Control function
5 Actuator size
www.gemu-group.com
Code 3 Diaphragm mounting
SUPM Pin
4 Control function
Code
Normally closed (NC)
B
Normally open (NO)
C
5 Actuator size
D
Actuator size 1T1
Code
SUPM Pneumatically operated actuator
metal version
B Diaphragm size B
G Pin
1 Normally closed (NC)
1T1 Actuator size 1T1
31 / 56
5.1 Pneumatic actuator SUPM
Description
Code
G
Code
1
2
Code
1T1
GEMÜ SUPM
