ATTENTION: If the values of the programming
menu A0 to A4 are changed, the load switch-off no
longer provides any protection! Teach the door operator in
again before re-commissioning. For this carry out
the door operator (Chapter 15) .
Menu
Function, setting range, unit
A0 Length SOFT RUN OPEN in 7cm
0..9
A1 Length SOFT RUN CLOSE in 7cm
0..9
A2 Soft running speed (CLOSE) mm/s
0= 50...9= 140
A3 Backjump, OFF= 0 ON= 1
A4 Change in direction, OFF= 0 ON= 1
Setting (with +/-) only possible if EMERGENCY
STOP plug (1, green) is unplugged.
A5 Added load
1)
OPEN 0..9
A6 Added load
1)
CLOSE 0..9
A7 Door type: Overhead sectional door/one-piece
door = 0
Side sectional door* = 1
Side sectional door with soft start = 2
* Obstruction release also in OPEN direction
If A7 was changed, perform a reset
and then teach in the door operator again.
(Chapter 15).
A8 Warning time (OPEN/CLOSE) 1=2secs...
8=16secs
A9 Accessory card
0= ZKMagicS
1= ZKMagic
b0 Relay 1 (with ZKMagic accessory card)
0= no function
1= E-lock
2= warning light *
3= photo cell test* (interruption transmitter
voltage)
4= status display*: Door in end position OPEN
5= status display*: Door in end position CLOSED
6= green light*
7= red light*
* if A9= 1
b1 Relay 2 (with ZKMagic accessory card)
0= no function
1= E-lock*
2= warning light *
3= photo cell test*
(interruption transmitter voltage)
4= status display*: Door in end position OPEN
5= status display*: Door in end position CLOSED
6= green light*
7= red light*
* if A9= 1
b2 Closing edge protection (accessory card)
0= OFF 1= OSE
b3 Empty run detection 0= OFF 1= ON
b4 Automatic closure function
0= OFF 1= 10 secs2= 30 secs
3= 1 min 4= 2 min5= 3 min
6= 5 min 7= 10 min8= 15 min
resp. plus warning time
16 / 206
Teaching in
Factory setting
2
4
5
1
0
3
3
0
(Chapter 19)
0
0
0
0
0
1
1) 0
IP2285 11/2017
b6 Maintenance interval*
0= OFF
1..9 (1,000 door movements)
Example: 5 = 5,000 door movements
The operator lighting flashes after every door
movement when the maintenance interval has run
out. A misadjustment resets the counter of the
maintenance interval.
b7 Version number: 8 digits are displayed twice in
succession with leading "-".
Example: -04200510 indicates:
Version: 04 Date: 20.05.10
b8 Service mode
0= control panel free, menu items adjustable
1= control panel locked, menu items not
adjustable
2= data output (accessory card)
Setting only possible if EMERGENCY STOP plug
(1, green) and photo cell (2, yellow) are
unplugged.
b9 Run counter: 8 digits are displayed twice in succession
with leading "-".
Example: -00008000 indicates:
8,000 runs
C0 Test mode for Magic-Door-Control (option)
Radio signal, maximum 15 seconds:
0= no signal
1= end position OPEN
2= end position CLOSED
3= run open
4= run close
5= standstill underway
7= error
8= obstruction
1)
If the added load (A5, A6) is >3 and/or the automatic
closing (b4) is set to ON (>0), the door may only be
operated with an additional safety device.
WARNING: to ensure that the closing force value comply with
limits established by the EN 12453 standard für door models
Basematic 42, Superior 42/+42/+42 WIDE with pass door,
Secura with pass door, Comfort with pass door and SSD, the
following parameters values must be set: A1 = 008; A2 = 003
and A6 = 000. This operation must be performed only by
qualified personnel.

19 Reset

ATTENTION: Ther is no longer any protection by
switching off the load after the reset. Teach the door
operator in again before re-commissioning. For this carry out
Teaching in the door operator (Chapter 15) .
Reset (saved values of the teach-in runs)
Press and hold buttons and menu
one of the 3 status messages A, B or C (see Chapter 10). The
display (r) flashes after a few seconds, then L4 is displayed
and the reset is made.
The remote transmitters are not deleted.
Reset, factory setting
• Pull out plug (1, green).
• During one of the 3 status messages A, B or C (see 10)
press the pushbuttons
longer than 12 seconds. The display flashes slowly at first,
then quicker (r). Then the status display reappears, the
reset is made.
The values shown under Programming (Chapter 18) are
set. The remote transmitters are not reset.
simultaneously during
and Menu simultaneously for
