Introduction
MANUFACTURER:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D­89335 Ichenhausen
DEAR CUSTOMER,
we wish you a pleasant and successful working expe-
rience with your new scheppach machine.
NOTE:
According to the applicable product liability law the
manufacturer of this device is not liable for damages
which arise on or in connection with this device in
case of:
improper handling,
•
non­compliance with the instructions for use,
•
repairs by third party, non authorized skilled work-
•
ers,
installation and replacement of non­original spare
•
parts,
improper use,
•
failures of the electrical system due to the non­
•
compliance with the electrical specifications and
the VDE 0100, DIN 57113 / VDE 0113 regulations
Recommendations:
Read the entire text of the operating instructions prior
to the assembly and operation of the device.
These operating instructions are intended to make it
easier for you to get familiar with your device and uti-
lize its intended possibilities of use.
The operating instructions contain important notes on
how to work safely, properly and economically with
your machine and how to avoid dangers, save repair
costs, reduce downtime, and increase the reliability
and working life of the machine.
In addition to the safety regulations contained herein,
you must in any case comply with the applicable reg-
ulations of your country with respect to the operation
of the machine.
Put the operating instructions in a clear plastic folder
to protect them from dirt and humidity, and store them
near the machine. The instructions must be read and
carefully observed by each operator prior to starting
the work. Only persons who have been trained in the
use of the machine and have been informed on the
related dangers and risks are allowed to use the ma-
chine. The required minimum age must be met.
18 І GB
 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58
In addition to the safety notes contained in the present
operating instructions and the special regulations of
your country, the generally recognized technical rules
for the operation of wood working machines must be
observed.

Device description (Fig. 1-2)

Handle/hand grip
1.
Switch lock
2.
3. Plunge-cut trigger
Suction nozzle
4.
Knob for angle adjustment
5.
6. Adjustment screw for guide rail
Rechargeable battery (dependent on the scope
7.
of supply)
8. Capacity display
Cutting depth stop with cutting depth display
9.
On/off switch
10.
Riving knife
11.
Saw blade
12.
Saw blade flange
13.
Rechargeable battery release button
14.
Shaft locking mechanism
15.

Scope of delivery

Open the packaging and remove the device care-
•
fully.
Remove the packaging material as well as the
•
packaging and transport bracing (if available).
Check that the delivery is complete.
•
Check the device and accessory parts for trans-
•
port damage.
If possible, store the packaging until the warranty
•
period has expired.
m ATTENTION
The device and packaging materials are not toys!
Children must not be allowed to play with plas-
tic bags, film and small parts! There is a risk of
swallowing and suffocation!
