Switching point 2 can be adjusted with the setpoint difference (XSH) function.
Value range: 0 % to 20 %
Through selecting the module selection function one returns to controller parameter mod-
ule selection.
Page 2 displays additional parameters on a second page of settings.
The following settings apply to the 2-point-FUZZY controller:
Electrodeless C
controller
parameters page 1
(2-point FUZZY)
The set point (W) function is used to specify the nominal value within the measuring
range. Value range (depending on the set measuring range):
Measuring range
0..2 mS
0..20 mS
0..200 mS
0..2000 mS
The FUZZY controller is informed of the system characteristic through the specified dead
time.
Value range: 0 sec to 60 sec
The setpoint difference (LW) function is used to specify the absolute interval between
switching point 2 and the set point.
Value range (depending on the set measuring range):
Measuring range Value range
0..2 mS
0..20 mS
0..200 mS
0..2000 mS
The switch difference (X2SD) function can be used to specify a switch hysteresis around
switching point 2. The stated percentage refers to the absolute value of switching point 2.
Value range: 0.0 % to 30.0 %
Through selecting the module selection function one returns to the controller parameter
module selection.
Page 2 displays additional parameters on a second page of settings.
417101800_Anhang01_LF_induktiv.doc
Conductivity Measuring Module (electrodeless)
Value range
0.000 mS to 2.000 mS
0.00 mS to 20.00 mS
0.0 mS to 200.0 mS
0 mS to 2000 mS
0.000 mS to 2.000 mS
0.00 mS to 20.00 mS
0.0 mS to 200.0 mS
0 mS to 2000 mS
