The metering time monitoring function of other possible controllers also remains unaf-
fected if an alarm is indicated. Where required, these are also turned off once they have
reached their max. metering time.
Value range: 10 sec to 9999 sec
The metering time monitoring function can be turned off with the Off setting.
NOTE
Through selecting the module selection function one returns to configuration module se-
lection.
The first page of the electrodeless C module configuration menu is opened through select-
ing page 1.
4.2

Measuring parameters

The main menu for adjusting the Multronic is accessed through operating the ↑ key in the
measuring mask.
Main menu
The measurement parameters are selected through placing the cursor onto the selected
item and operating the ENTER key.
Measurement
parameter module
selection
(not available at
Multronic OC!)
The electrodeless C-measuring module that is to be parametered can now be selected.
To do so, move the cursor onto the corresponding selected item and operate the ENTER
key.
The following measurement parameters can be adjusted for the electrodeless C-
measuring module.
Measurement
parameter
electrodeless C
The measuring range function is used to changes the measuring range.
Value range: 0..2 mS / 0..20 mS / 0..200 mS / 0..2000 mS
417101800_Anhang01_LF_induktiv.doc
Conductivity Measuring Module (electrodeless)
The time periods for the controllers must be within realistic limits.
min. controller on-time < controller cycle time < max. metering time
- 42 - Rev. 06-07/10
