MSA501-S(RS485)
SIKONETZ3 interface
Meaning of the status bits in the system status
Data byte low:
Data byte middle:
Data byte high:
The message is active if the bits = "1". Bit0 ... Bit7 cannot be deleted and
are always up-to-date (dynamic). Bit8 ... Bit23 are set automatically, but
must be deleted manually via the 3Bh command (delete system status)
(static).
MSA501-S(RS485) · Date 06.06.2016 · Art. No. 85614 · Mod. status 152/16
Bit0: always 0
Bit1: always 0
Bit2: always 0
Bit3: position value frozen
Bit4: always 0
Bit5: programming state
Bit6: always 0
Bit7: always 0
Bit8: always 0
Bit9: error 02 occurred
Bit10: error 03 occurred
Bit11: error 05 occurred
Bit12: always 0
Bit13: always 0
Bit14: always 0
Bit15: always 0
Bit16: always 0
Bit17: always 0
Bit18: sensor-tape distance exceeded
Bit19: plausibility error absolute value
Bit20: always 0
Bit21: always 0
Bit22: travel speed >5 m/s
Bit23: always 0
