Abbildung 4: Servopositionierregler Ars-310/5 (Ul): Einbaufreiraum - Metronix ARS-310/5 Produkthandbuch

Seite 48
100 mm Einbaufreiraum für eine ausreichende Belüftung
des Servopositionierregler ARS-310/xx
