General Notes - Scheppach 1901501901 Originalbetriebsanleitung

Manufacturer
Scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
We wish you much pleasure and success with your new
scheppach machine.
Note
In accordance with valid product liability laws, the manu-
facturer of this device shall not be responsible for dam-
age to and from this device which results from:
• Improper care.
• Noncompliance with the Operating Instructions.
• Repairs made by unauthorized persons.
• The installation and use of any parts which are not
original scheppach replacement parts.
• Improper use and application.
• Failure the electrical system as a result of noncompli-
ance with the legal and applicable electrical directives
and VDE regulations 0100, DIN 57113 / VDE 0113.
We recommend
that you read through the entire operating instructions
before putting into operation.
These operating instructions are to assist you in getting
to know your machine and utilize its proper applications.
The operating instructions contain important notes on
how you work with the machine safely, expertly, and eco-
nomically, and how you can avoid hazards, save repair
costs, reduce downtime and increase the reliability and
service life of the machine.
In addition to the safety requirements contained in these
operating instructions, you must be careful to observe
your country's applicable regulations.
The operating instructions must always be near the ma-
chine. Put them in a plastic folder to protect them from
dirt and humidity. They must be read by every operator
before beginning work and observed conscientiously.
Only persons who have been trained in the use of the
machine and have been informed of the various dangers
may work with the machine. The required minimum age
must be observed.
In addition to the safety requirements contained in these
operating instructions and your country's applicable reg-
ulations, you should observe the generally recognized
technical rules concerning the operation of woodworking
machines.

General notes

• After unpacking, check all parts for any transport dam-
age. Inform the supplier immediately of any faults.
• Later complaints cannot be considered.
• Make sure the delivery is complete.
• Before putting into operation, familiarize yourself with
the machine by carefully reading these instructions.
14 І 120
 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58
• Use only original scheppach accessories, wearing or
replacement parts. You can find replacement parts at
your scheppach dealer.
• When ordering, include our item number and the type
and year of construction of the machine.
Scope of delivery
Longitudinal stop
Operating instructions
Guiding profile with scale
Adapter for Suction
Hexagonal spanner SW 10
Hexagon socket head wrench
Technical data
Passage width mm
Passage height mm
Table size mm
Cutting speed m/
min.
Saw band length mm
Saw band
width mm
Height up to tabletop
mm
720 x 475 x 440
H x W x D mm
Slewing range of the
table°
Overall weight kg
Suction connection
ø mm
Band wheel ø mm
Motor
230–240V/50 Hz
Electro motor
Nominal
consumption P1 kW
Delivery of power
P2 kW
Operating mode
Revolutions 1/min
Motor protection
Under voltage
release
Switch
Subject to technical modifications!
Legend Fig. 1
1. Case door
2. Door lock
3. Saw blade safety device
4. Saw blade guidance
5. Longitudinal limit stop
6. Tabletop
7. Frame
8. On/Off switch
9. Handle for saw blade tensioning
Band saw
Sawing table
Push stick
Accessory bag
SW3/SW6
196
100
310 x 320
880
1490
3,5/12
315
0-45
25
100/35
205
0.30
0.18
S1
1,355
no
yes
Schuko
