9.4 Feldbus Verdrahtung
9.4.1 Comm Box (Metall)
Abbildung 35: RS485 Anschlussleiste für Comm Box (Metall)
X1 Pin
Terminal
L
ED
L
Abbildung 36: Profibus und Modbus Anschlussleiste
MI3
Profibus
1
(negatives Signal)
2
(positives Signal)
3
Schirm
4
GND
5
nicht benutzt
6
+ 5 V
, gelb
blinkend:
0.5 Hz: Parameter
1 Hz: Konfiguration
, rot
AN: Datenaustausch
ED
Rev. C1 03/2012
Terminierung
Modbus
A
(negatives Signal)
B
(positives Signal)
Schirm
GND
nicht benutzt
+ 5 V
Kommunikation
Fehler
Feldbusse
D0
D1
77
