Start Size Modbus
address [bits] Access
110 8 discretes
input
120 16 holding
register
130 16 holding
register
410 32 input
register
420 32 input
register
430 16 input
register
5<k>0 16 holding
register
5<k>1 16 holding
register
5<k>2 16 holding
register
5<k>3 32 holding
register
5<k>5 32 holding
register
5<k>7 32 holding
register
MI3
Data Content
Type
bit field Get registred
heads
short Laser control (only
with laser)
short Relay alarm output
control
float ana. input 1 value 0 .. 5 V
float ana. input 2 value 0 .. 5 V
short Trigger
short ana. output k
mode
short ana. output k
source
short ana. output k
source parameter
float ana. output k fixed
temp. value
float ana. output k
bottom temp.
value
float ana. output k top
temp. value
Rev. C1 03/2012
Programmierung
Values
bit 0: head 1 ..
bit 7: head 8
bit high: head registered
bit low: head not registered
0: off, 1: on
0: off
1: on
2: norm. open
3: norm. closed
0: off
1: on
5: TCJ
6: TCK
7: TCR
8: TCS
9: 0...5 V
10: 0...10 V
99: disable (tristate)
head number or 0:
fixed value from 5<k>3
1: internal temp. of 5<k>1
2: object temp. of 5<k>1
value within range set in
address 5<k>0
device bottom temp. .. device
top temp.
device bottom temp. .. device
top temp.
MI3[M]
command
HCR
XL
KB
TV1I
TV2I
XT
XO<k>O
O<k>O
O<k>O
-
L<k>O
H<k>O
