Programmierung
14.3.2.2 Kopfparameter
<n> ... Kopfnummer, abhängig von Anzahl der registrierten Köpfe
Starting Size Modbus
address [bits] Access
<n>005 8 discretes
input
<n>010 64 input
register
<n>020 64 input
register
<n>030 64 input
register
<n>040 16 input
register
<n>050 32 input
register
<n>060 32 input
register
<n>070 32 input
register
<n>080 32 input
register
<n>090 32 input
register
<n>100 32 holding
register
<n>110 32 holding
register
148
Data Content
Type
bit field Head Status
hex Head serial
number
string Head
identification
string Firmware Rev.
Head
short Head Address 1 .. 9
string Head special
float Device Bottom
range
float Device High
range
float Target
temperature
float internal sensor
temp.
float Ambient
background
temp. comp.
float Advanced hold
with average
Rev. C1 03/2012
Values
bit0: Temperature Unit
(0: deg. C, 1: deg. F)
bit1: Object temperature out of
range
bit2: Ambient temperature out
of range
bit3: Parameter error
bit4: Register write error
bit5: Self-test error
bit7: Background temp.
compensation (0: off, 1: on)
e.g. 10C02752
e.g. "MI310LTS"
e.g. 2.10
e.g. !99HSRAY (read only)
-40 .. 1300 [°C]
-40 .. 1300 [°C]
number within range <n>060 ..
<n>070
0 .. 999.9 [s]
MI3[M]
command
HEC
HN
HI
HV
HA
HS
XB
XH
T
I
A
AA
MI3
