Programmierung
14.3.2.1 Boxparameter
<k> ... Anzahl der Ausgabekanäle, entspricht der Anzahl der
physisch installierten Ausgabekanäle der Kommunikationsbox.
Items (registers, discretes or coils) are addressed starting at zero.
Therefore items numbered 1-10000 are addressed as 0-9999.
Start Size Modbus
address [bits] Access
1 16 input
register
10 64 input
register
20 64 input
register
30 64 input
register
40 16 input
register
50 32 input
register
60 32 holding
register
70 16 holding
register
80 32 input
register
90 16 holding
register
100 8 discretes
input
146
Data Content
Type
short error code for last
request
hex Serial number
string Unit identification e.g. MI3COMM
string Box Firmware
Revision
short Modbus slave
address
string Box special
integer Baud rate RS485 9600, 19200, 38400, 57600,
char Temperature Unit 0x43 ('C'), 0x46 ('F')
float Box Temperature
short Switch panel lock 0: unlocked, 1: locked
bit field Get connected
heads
Rev. C1 03/2012
Values
0: no error
1: value out of range
2: illegal head number
3: illegal analog output number
4: illegal output mode
5: output disabled error
99: unspecified error
e.g. 98123
e.g. 2.10
1 .. 247
e.g. RAY, LAS
115200
bit 0: head 1 ..
bit 7: head 8
bit high: head connected
bit low: head disconnected
MI3[M]
command
-
XV
XU
XR
XA
DS
BR
U
XJ
J
HC
MI3
