Starting Size Modbus
address [bits] Access
<n>120 16 holding
register
<n>130 16 holding
register
<n>140 16 holding
register
<n>150 32 holding
register
<n>160 32 input
register
<n>170 32 input
register
<n>180 32 holding
register
<n>190 32 holding
register
<n>200 32 holding
register
<n>210 16 holding
register
<n>220 16 holding
register
<n>230 32 holding
register
<n>240 32 holding
register
<n>250 32 holding
register
<n>260 32 holding
register
<n>270 32 input
register
MI3
Data Content
Type
short Control ambient
background
temp. comp.
short Laser control
(only with laser
device)
short Relay alarm
output control
float Advanced hold
threshold
float Currently
calculated
emissivity
float Current
calculation
setpoint / relay
function
float Sensor Gain
float Sensor Offset
float Emissivity
internal
short Presel.
Emissivity
Pointer
char Emissivity
Source
float Presel.
Emissivity
float Valley hold time 0.0 .. 998.9s (999: infinite)
float Average time
float Peak hold time 0.0 .. 998.9 [seconds] (999:
integer Power / AD
value
Rev. C1 03/2012
Programmierung
Values
0: sensor temp.
1: via number
2: via ext. input
0: OFF, 1: ON
0: off
1: Target
2: Ambient
number within range <n>060 ..
<n>070
0.1 .. 1.1
number within range <n>060 ..
<n>070
0.8 .. 1.2
-200 C .. +200 C
0.1 .. 1.1
0 .. 7
I: internal command
E: ext. input (0V .. 5V)
D: digital selected FTC1-3
0.1 .. 1.1
0.0 .. 999.0 [seconds]
infinite)
MI3[M]
command
AC
HL
KH
C
CE
CS
DG
DO
E
EP
ES
EV
F
G
P
Q
