Setting Audio Input And Output Behavior - Blackmagic Design Atem Mini Installationsanleitung

Supported Video Input Standards
HD Video Formats

Setting Audio Input and Output Behavior

The 'audio' tab lets you control the nature of the audio follow video feature plus set the mic
inputs to mic or line level audio. Microphones typically have weaker signals compared to line
outputs from other audio devices. This means when mic is selected, the input is boosted
slightly to compensate. This also means that if mic is accidentally selected when a line level
input is plugged in, the audio will sound unusually loud. If the audio sounds much louder than it
should be, check that line is selected instead of mic.
Split Audio
Split a mono input signal into two separate mono channels. This is helpful for mixing a mono
input into both channels on the stereo master output. You can also add a stereo simulation
effect using the advanced Fairlight controls on the audio page.
Click on the desired input checkbox to split the channels for that input.
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97,
1080p30, 1080p50, 1080p59.94, 1080p60
1080i50, 1080i59.94, 1080i60
Changing Switcher Settings 93
