Macros Window Create Page
Create macro button:
Click this button to open the
create macro popup window.
From here you can name a
new macro to be recorded,
write a description of your
macro in the notes section,
and click record to start
recording your macro.
Arrow buttons and
page Icons:
To access or record more
than 20 macros, simply click
on the right arrow at the
bottom corner of the macros
window to open a new page
of macros. To move to the
previous page of macros,
click on the left arrow. You
can see which page of
macros you are viewing by
observing the page icons
between the arrows.
Macros Window Run Page
Recall and Run:
Selecting the Recall and Run
feature lets you instantly run
a macro by clicking a macro
button. Deselecting the Recall
and Run feature lets you load
a macro by clicking on your
macro button. Run the macro
by clicking the play button.
Edit macro button:
First select the macro you want to edit,
then click on the edit macro button to edit
the name and description of the macro.
Delete macro button: Select the macro
you want to delete, then click on the delete
macro button to delete the selected macro.
Macro buttons:
After recording a macro to a selected
macro slot, your macro will appear as a
macro button. 20 macro buttons can be
displayed on one page. If a macro is
unnamed when recording, the number
of the selected macro slot will be used.
Status window:
This window provides helpful prompts
and status messages to help you get started
recording and running your macros. When a
macro is selected, it also displays any notes
you have included.
Play:
When Recall and Run is deselected and you
have loaded a macro by clicking on a macro
button, click the play icon to start playing
the macro.
Stop:
Clicking the stop button will stop the
playback of a macro, but will complete the
current action first. For example, if you
press stop half way into a transition, the
switcher will finish the transition and
then stop.
Loop:
When the loop button is selected and
you run a macro, your macro will run
continuously until you click the stop button.
When loop is deselected, your macro will
run until it is completed.
