Connecting to an Internet Router

On ATEM Mini Pro or Extreme model switchers, connecting to an Internet router via Ethernet
lets you stream your broadcast over Ethernet while using the USB-C connector to record to an
external drive.
To set up direct streaming via Ethernet, first enter the stream details in ATEM Software Control.
This will store the streaming information in the switcher.
1 In ATEM Software Control's processing palettes go to the 'output' settings and select your
streaming platform from the platform menu.
2 Enter the server closest to your location in the 'server' menu, then enter your stream key in
the 'key' setting. Refer to 'getting a stream key' in the next section for more information.
3 With the details entered into ATEM Software Control, now plug your switcher into the
Internet router using a CAT 5 network cable. This is usually a wireless router that connects
all your home or office devices to the Internet. The unit will normally have additional
Ethernet inputs and you can plug your switcher directly into one of those.
TIP If your computer is connected to the Internet router and has an Ethernet port, you
can also connect ATEM Mini Pro or Extreme switcher to your computer via Ethernet
and connect to the Internet via your computer.
4 It's worth streaming a test to make sure everything is set correctly. You can do this by
switching color bars, or a standby graphic in the media player to the program output and
checking you can see it on your streaming platform.
Now if you are happy and ready to start, all you need to do is press 'on air' and you are
broadcasting live!
NOTE Most internet routers support DHCP, but if yours does not, you can still connect
by setting the network settings manually using Blackmagic ATEM Setup.
