Mix Transitions

A mix is a gradual transition from one source to another and is achieved by interpolating
gradually between two sources, effectively overlapping the sources for the duration of the
effect. The length of the transition or length of the overlap can be adjusted by changing
the mix rate.
Program output for a mix transition.
To perform a mix transition on the ATEM 1 M/E Advanced Panel:
1 On the preview bus, select the video source that you want on the program output.
2 Press the MIX button to select the mix transition type. The LCD menu will automatically
display the transition settings.
3 In the transition settings, use the corresponding LCD control knob to adjust the mix rate.
You can also enter a rate duration using the number pad.
4 Perform the transition as an auto transition or manual transition from the transition
control block.
Press the 'mix' button and set the transition rate using the LCD menu
Mix Transition Parameters
Rate The mix transition rate in seconds : frames.
