Control Panel Tab

The control panel tab features settings to change the panels button mapping and colors.
Switcher to Control
ATEM Micro Panel can control any connected ATEM 1 M/E, 2 M/E or 4 M/E switcher. To make
sure all the inputs for your switcher are available for button mapping, use the 'switcher to
control' menu to select the correct model. This will either narrow down the available inputs to
8 for ATEM Mini or increase them to 40 for ATEM 4 M/E Constellation switchers.
Button Mapping
Using the button mapping setting you can assign inputs to specific buttons on the program
preview rows of the ATEM Micro Panel. Any button mapping you apply in ATEM Setup will be
independent of the button mapping in the software control panel for the same switcher. This
means you could have a different button layout on the ATEM Micro Panel compared to the
software control panel for the same switcher. You can also change the color of the buttons for
the program and preview buses to help them stand out more when needed.
To assign a source to a button:
1 Click on the menu beside the button you want to assign a source to. You will notice the
button will illuminate in the software to show use which button you are mapping.
Using ATEM Micro Panel 157
