Blackmagic Design ATEM Mini Installationsanleitung Seite 28

3
Click on the 'server' setting menu list and select
the server nearest to your location.
5
Set the streaming quality to low, medium,
or high. This will also set the quality for the
recording output via USB-C.
You are now on air! To check your broadcast, click on your account avatar and select 'back to
Twitch'. Once in the main Twitch window, click your avatar icon again and select 'channel'. You
will now see your broadcast on your channel and the live indicator will appear at the top of
the window.
NOTE If you are using additional ATEM control panels with your ATEM Mini, then you
might need a dedicated IP address. For more information, refer to the 'connecting to a
network' section.
Direct Streaming by Sharing Your Computer Internet
With ATEM Software Control now connected to your switcher, you can set up a direct stream via
your computer's Internet connection.
To set up your ATEM Mini Pro or ATEM Mini Extreme for software control and direct streaming:
1 Plug your ATEM into your computer's spare Ethernet port. It may take a moment for DHCP
to find the unit and assign an IP address.
2 Launch ATEM Software Control.
3 You will see ATEM Mini Pro or ATEM Mini Extreme listed as a connected ATEM switcher on
your network. Simply select your switcher from the list.
4 Click 'connect'.
5 Configure your computer to share its Internet connection through its Ethernet port.
4
In the 'key' setting, paste the stream key you
copied from Twitch.
6
With all the streaming details now set, it's worth
performing a quick test broadcast to make sure
everything is working. Press the 'on air' button
on ATEM Mini Pro or Extreme switcher, or click
on the on air button in the live stream palette.
Additional Features on ATEM Mini Pro and ATEM Mini Extreme 28
