10 Sensor replacement/data storage
11 Disposal
12 Technical data
12.1 Technical data
8024108.1GKT/2024-12-03 | SICK
Subject to change without notice
No modifications may be made to devices.
Subject to change without notice. Specified product properties and technical data are
not written guarantees.
All IO-Link devices have a backup and restore functionality - Data Storage (DS). The
IO-Link Data Storage function can be used to save previous parameters and transmit
them to the replacement device.
The prerequisite for this is connection of the device to an IO-Link Master, and activation
of the storage function in the IO-Link Master.
Details on sensor replacement can be found in the detailed IO-Link description:
cal Information: Photoelectric sensors, SICK Smart Sensors /
The product must be disposed of in line with applicable country-specific regulations.
When disposing of them, you should try to recycle them (especially the precious met‐
als).
NOTE
Disposal of batteries, electric and electronic devices
• According to international directives, batteries, accumulators and electrical or
electronic devices must not be disposed of in general waste.
• The owner is obliged by law to return this devices at the end of their life to the
respective public collection points.
•
WEEE: This symbol on the product, its packaging or in the document
indicates that a product is subject to the specified regulations.
Laser class
Sensing range
Sensing range max.
Light spot size / distance
Supply voltage U
B
Output current I
max.
Switching frequency
Response time
Enclosure rating
O P E R A T I N G I N S T R U C T I O N S | PowerProx Small Teach-in - WTT190LC-B2233A00
OPERATING INSTRUCTIONS
Techni‐
IO-Link.
WTT190LC-B2233
1
0.2 ... 3.0 m
1)
0.2 ... 3.0 m 1)
< 12.0 mm / 3,0 m
DC 12 ... 30 V
≤ 100 mA
AVG 1: 833 Hz, AVG 4: 500 Hz, AVG
16: 147 Hz, AVG 64: 38 Hz, AVG
256: 10 Hz 2) 3)4)
AVG 1: 0.6 ms, AVG 4: 1 ms, AVG 16:
3.4 ms, AVG 64: 13 ms, AVG 256:
51.4 ms 5) 3)4)
IP67
