WING COMPACT Quick Start Guide
WING COMPACT Overview
7. Firmware updates
The WING console rmware can be easily updated via USB. Download the rmware le from the product page on behringer.com and follow these steps:
1. Open the SETUP/GENERAL page and click on WING OS.
2. Connect a USB cable to the rear panel port and to your computer.
3. A virtual drive will appear on your computer, similar to connecting a ash drive or external hard drive. Double click the drive to open.
4. Drag the new rmware le into the drive. Although WING always boots using the most recent rmware in that drive, it is recommended to delete older rmware
les or move them to a subfolder.
If the console does not boot up normally, you can still update the rmware using this procedure:
1. With console powered o , connect a USB cable to the rear panel port and to your computer.
2. Press and hold the button below the main meter to the right of the Main Display, then power the console on.
3. An OS and DATA drive will appear on your computer, similar to connecting a ash drive or external hard drive. Double click a drive to open.
4. Drag the new rmware le into the OS drive.
Note, WING will always boot using the most recent rmware in that drive.
5. After the le has transferred, eject the virtual drive. The console should reboot automatically with the new rmware installed. If it doesn't, power cycle the
console manually.
8. Shortcuts
PURPOSE
ENTER MODE
EFFECT
Hold SETUP, ALT (unlabeled
No touch events will have any e ect, while the small X is shown.
Deactivate Main Display
button) and CLR SOLO,
The console will keep operating as usual otherwise.
touch control
until a small X is shown in the
Leaving this mode will calibrate the touch interface and render it
status bar of main display
operational again.
Hold ALT (unlabeled
Resets the touch panel (might help to temporarily x ghost touch
button) and CLR SOLO
issues for some time)
for > 1.5s
Touch UI >
Hold METERS and HOME for 5s
Ghost Click Test
while powering the console up
Hold ALT (unlabeled button)
Console appears as two drives on your computer (WING OS for the
OS-Drive > mount USB
while powering the console up
console operating system, and WING DATA for snapshots, etc.).
(screen stays dark)
Hold EFFECTS and press HOME
Shutdown and Restart
after initiating Shutdown from
Console will shut down safely and restart automatically
Setup screen
Hold ALT (unlabeled button)
Same as OS-Drive mode. Surface is in test mode until console
Surface > Test Mode
while powering the console up
boots up.
Locks the console surface, while audio and remote control keep
working una ected.
Hold the HOME button down
Any combination of buttons (only those around the touch screen)
Surface Lock
for ~1.5s
that was held down while engaging the lock will be stored
as "pass code" for unlocking. You will need to press the same
combination of buttons when disengaging the Lock.
Initialize console (only
Same as using INITIALIZE (from the SETUP page) but before the
temp storage, no
Hold CLR SOLO while powering
console loads any saved state (in case the last loaded snapshot
snapshots etc. will be
the console up
somehow crashes the console leading to a boot loop)
erased)
Stores a bmp of the current screen on your USB drive. A folder
Take screenshot
Hold CLR SOLO then press UTILITY
called 'screens' needs to be created in the root of the USB
drive rst.
Bypass automatic load of
Hold LIBRARY while powering the
Does not load STARTUP*.snap, STARTUP*.snip and STARTUP*.show
startup les
console up
les in the STARTUP directory during boot
Con guring optional
hardware, i.e. internal
Hold UTILITY for 5s while
Con guration dialog allows to specify the hardware option
AoIP modules for Dante
powering on
or WSG
29
Quick Start Guide
EXIT
Hold ALT and CLR SOLO until
the X disappears
Eject the drives on your
computer
Hold HOME button for ~1.5s
again together with the "pass
code" of buttons that were
pressed while locking,
OR
power-cycle the console
