WING COMPACT Quick Start Guide
WING COMPACT Overview
The SAVE button saves all the console's settings. SAVE+SCOPE allows the user to select speci c content to be saved for speci c channels. The NONE and ALL buttons
allow a quicker selection of the desired content.
The snapshot will be saved either on the console's internal storage or on the USB ash drive connected to the front panel, depending on which location is selected on
the top left corner of the screen.
After changes have been made to the console's settings, these can be saved to a preexisting snapshot by clicking on the desired snapshot and then clicking on UPDATE.
If only speci c channels or contents should be updated, click on PARTIAL UPDATE and select the desired settings.
To load a snapshot with or without a de ned scope, click on LOAD. A snapshot will always store all the parameters but only recall the speci ed ones when SAVE+SCOPE
is used. To edit the SCOPE of an existing snapshot, click on EDIT SCOPE. Speci c settings can also be loaded from a complete snapshot with the PARTIAL LOAD button.
SNIP
Snippets can be used to recall more precise settings adjustments like speci c processor changes in the channel strip. To select which settings will be stored in a
snippet, click on the REC button and manually adjust the desired settings. The number of modi ed parameters will be displayed on screen. Make sure to click on STOP
after all the changes have been made.
It is possible to add or remove parameters from a snippet using the ADD ITEMS and REMOVE ITEMS buttons.
GLOBAL
Any channel, bus, source, output, DCA, mute group or e ect and its associated contents can be protected against being overridden when loading snapshots or
snippets. To do so, click on the GLOBAL button on the top right-hand corner of the screen and specify what needs to be protected. Whenever a setting is protected, the
lock icon will turn red.
CLIP
The WING console can play .wav les from previously copied from a computer to the internal storage via the WING DATA USB connection, a USB ash drive connected to
the front panel or .wav recordings made by the console and stored on a USB ash drive or on up to two SD cards in the rear panel.
Clips can be selected on the left panel and played using the right panel.
FX
The e ects loaded on the 16 slots of the EFFECTS screen will show up on the FX screen. The set up of the 16 slots can be stored and recalled.
CHAN
Individual channels can also be stored and recalled. All the channel settings will be saved when using this feature. Upon loading, only the selected con gurations will
be loaded.
SHOW
Snapshots, snippets, clips, FX setups and channel setups can be grouped and saved as Shows. To do so, go to the SHOW tab and click on CREATE. Navigate to the desired
item on the internal storage or ash drive, make sure the SHOW tab is open and then click on the ADD ITEM TO SHOW button.
Click on the SAVE button in the SHOW tab.
Items in a Show can be arranged in a speci c order. The item order will be shown when the lm icon is selected.
The items can be navigated using the SHOW CNTRL button on the center section of the console. PREV and NEXT select the items. GO triggers each item. GO+PREV and
GO+NEXT select and trigger the items automatically.
UTILITY
This button does not have its own screen, but rather works in conjunction with other screens. The function is context relative, so pressing the UTILITY button may
bring up additional options or settings for con guration, depending on which screen is currently active.
