16 m , at least 2 m long and wide)
2
In rooms with beams (e.g.,
wooden beams), the number
and arrangement of the devices
depends on the height of the joists
and the surface formed by the
beams.
4.2 Requirements for the
monitoring area
When selecting the appropriate monitor-
ing area, observe the following:
f Position the device centrally on the
ceiling.
f Position the master or shared radio
group at a central location
(e.g. in the corridor).
f If possible, maintain an approxi-
mately equal distance between the
master and all other devices in a
radio group.
f Maintain an approximately equal
distance between the shared radio
group and other radio groups.
f If necessary, install additional
devices.
EN
EN
User Manual: XSD200 - Smoke Alarm Device with Radio Link
f Keep a minimum distance of 2 m
to electronic, radio-based devices
(e.g. Wi-Fi router).
f Keep a minimum distance of 3 m
to other smoke alarm device with
radio link.
f Observe the maximum installation
height of 6 m.
f Keep a minimum distance of 0.5 m
to surrounding walls, furniture and
lamps.
f Keep a maximum distance of 6 m
to a potential fire source.
Areas susceptible to draughts Areas susceptible to draughts
For occurring smoke to be able to reach
the smoke alarm device, there must
not be any strong draughty influences
around the installation site (e.g. caused
by air conditioning systems or ventila-
tion intakes or fans). In rooms with forced
ventilation, perforated ceilings which
are used for ventilation must be closed
off within a radius of 0.5 m around the
alarm device.
