3.2 Components
Fig. 10 Components
1 Splint pin (activation backup)
2 Activation button
3 Magnet carrier
EN
EN
3.2 Controls
Fig. 1 Controls
1 Splint pin (activation backup)
2 Activation button
3 Magnetic carrier
4 Signal LED
User Manual: XSD200 - Smoke Alarm Device with Radio Link
5 Radio button
4 Signal LED
5 Radio button
6 Smoke intake lamellas
7 Testing/stop button
(smoke alarm device cover)
1
2
3
4
5
6
7
