• Start the engine with care, in accordance with the
manufacturerʼs instructions. Make sure that your
feet are far enough away from the mower blade!
• Do not tilt the lawn mower when you start the engine
unless the mower must raised off of the ground a lit-
tle in order to start it. In the latter case, tilt the mower
as little as absolutely necessary and only raise the
side opposite to that of the user.
• Never start the engine while standing in front of the
chute.
• Never move your hands or feet toward or under any
rotating parts. Keep clear of the chute opening at
all times.
• Never lift or carry a lawn mower with the engine run-
ning.
• Switch off the engine and pull the spark plug boot
and make sure that all moving parts have come to
a standstill:
- before you dislodge any blockages or clogs in
the chute.
- before carrying out any checks, cleaning, main-
tenance or other work on the lawn mower
- if the lawn mower strikes a foreign body, examine
it for signs of damage and carry out any neces-
sary repairs before restarting and continuing to
work with the mower. If the lawn mower begins
to experience exceptionally strong vibrations,
immediately switch it off and check it.
• Switch off the engine:
- when you leave the lawn mower.
- before you refuel.
• Operation of the machine at higher than normal
speed can lead to an increased risk of accidents.
• Take care when carrying out installation work on the
machine, and avoid trapping fingers between the
moving cutting tool and the fixed parts of the ma-
chine.
• Please be particularly careful when mowing on
ground that may subside, on nearby landfills, trench-
es and embankments.
• The user must be adequately trained in the use,
adjustment and operation of the machine (including
prohibited operations).
• Check the machine regularly and ensure that all
start locks and push buttons are working properly
before each use.
• Please note that improper maintenance, the use of
inappropriate spare parts, or the removal or modifica-
tion of safety devices can result in damage to the ma-
chine and serious injury to the person working with it.
• Please note that the lawnmower's safety systems
or devices must not be manipulated or deactivated.
• Please note that the user must not change or ma-
nipulate any sealed engine speed control settings.
• Only use cutting equipment and accessories recom-
mended by the manufacturer. The use of other tools
and accessories may result in injury to the operator.
• Always keep the lawnmower in good operating con-
dition.
• It is necessary to take enough breaks to reduce
noise and vibration exposure.
Residual risks and accident prevention standards
Neglect of ergonomic principles
Negligent handling of personal protective equip-
ment (PPE)
Negligent handling or ommission of the personal pro-
tective equipment may cause serious injuries.
- Wear prescribed personal protection equipment.
Human behaviour, misbehaviour
- For any work be fully concentrated.
m Residual risks - Cannot be entirely excluded.
Danger from noise
hearing damage
Prelonged unprotected work with the device may
cause hearing damage.
- Always wear ear-muffs.
In case of emergency
In case of a possibly occuring accident take the neces-
sary first aid steps as appropriate and obtain qualified
medical aid as quickly as possible.
6. Technical data
Type engine
Cubic capacity:
Rotation speed
Max. engine output
Fuel
Capacity tank
Motor oil
Capacity tank/oil
www.scheppach.com
four stroke engine/
air cooled
131 cm
3
2800 rpm
2.4 kW / 3.3 HP
Regular petrol/unleaded
max. 5% bioethanol
1.0 l
SAE 30/10W30/10W40
0.4 l
