Connecting The Earthing - Auerswald COMpact 5000R Inbetriebnahmeanleitung

Warning: Liquid entering the casing can cause life-threatening electric
shocks or damage/destroy the PBX.
Caution: Overheating can damage or destroy the system.
Important: Mechanical loads and electro-magnetic fields can impair PBX
operation.
1.
Hold the drilling template onto the area where the device is to be mounted
and place marks where the three mounting holes are to be drilled into the
wall.
2.
Drill the mounting holes (diameter 6 mm) and insert dowels into the holes.
3.
Screw in the two upper screws far enough so that the screw head is about
5 mm away from the wall.
4.
Mount the PBX on the screws, then slide the PBX on the wall downwards
until the screws hit the stopper.
5.
Secure the PBX by tightening the third screw.

Connecting the Earthing

Requirements
– Tools and material:
– Earth wire in the immediate vicinity of the installation site (potential com-
pensation bar of the house installation or protective earth conductor)
COMpact 5000/R - Firmware Version 6.2 - Setup V01 03/2014
Only operate the device in closed, dry rooms.
Note the ambient temperature values indicated in the technical data.
Make sure that heat produced by the device can be adequately vented
into the environment. Do not install the system in a cabinet without ade-
quate air circulation.
Never cover the air vents of the casing.
Avoid mechanical loads (e. g. vibrations).
Avoid proximity to devices that generate electro-magnetic fields or react
sensitively to them (e. g. radio receivers, amateur radio sets, mobile
phones, DECT systems, or similar).
Protect the PBX from soiling, dust, and condensation.
Screw driver
Connecting cable with at least 2.5 mm
Preparation (COMpact 5000)
²
conductor cross-section
75
