Important Information

Announcement Output

The PBX can only be extended with announcement outputs by connecting the
corresponding accessories. See Ethernet port and internal analogue port.

Installation

The PBXs are intended to be operated in closed rooms. In addition, all of the
devices connected to the system must be located inside the building.
The PBXs enable you to connect some devices directly, inasmuch as they are
close enough to the PBX. The distance depends on the length of the equipment
connection cables up to a maximum of 10 m.
If no suitable connection sockets are available or are too far away, you must lay
the installation cable permanently.
Warning: Power surges, which can occur during electrical storms, can
cause life-threatening electric shocks.
Important: Improper use may cause, e.g. functional restrictions or interfer-
ence, the destruction of the device or, in a worst case scenario, personal
injury.
Note: For the COMpact 5000R, no connections are made directly to the
module itself but rather on the front panel.
Accessories and service parts can be bought at specialised stores or in the
Internet shop distriCOM (see www.districom.de). Delivery is provided only
in Germany and to Austria.

Configuration and Administration

The configuration manager on the PBX is contained in the integrated web server
and can be opened with a browser. This prevents the need to install special pro-
grammes on the computer. You need only an IP-supported operating system
and a compatible browser.
The configuration manager enables you to do the following tasks:
62
Let a qualified electrician lay all the cables inside the building – including
the cable to the door terminal system.
Do not use the a/b ports to connect external private branch exchanges.
Only connect equipment that is compatible with the proper use of the
PBX.
Configure the PBX
Manage the recorded voice and fax messages
Manage call data
COMpact 5000/R - Firmware Version 6.2 - Setup V01 03/2014
