Auerswald COMpact 5000R Inbetriebnahmeanleitung Seite 65

Connection type
Supply voltage
Feeder
Range
Terminators
Internal U
Connection unit
Connection types
Range
Supply voltage
Feeder
External S
Connection unit
Connection type
Range
Terminators
External Analogue Port
Connection unit
Type of dialling
Reception amplification
COMpact 5000/R - Firmware Version 6.2 - Setup V01 03/2014
S
0
(DSS1), short passive bus
40 V +5 % / -15 %
Max. 4 W
Max. 150 m with typical telephone or network cable (twisted-
pair) for bus setup; European standards ENV 41001
[DINV 41001] and EN 28877 apply to IAE-termination technol-
ogy)
100 Ohm, switchable; factory settings on
Port
P0
COMpact 5000: Spring clamp connection (2-core),
optionally RJ-45 socket
COMpact 5000R: RJ-45 socket
U
P0
direct connection to a U
Screened cable: up to 600 m;
unscreened cable: up to 1000 m
40 V +5 % / -15 %
Max. 4 W
Port
0
COMpact 5000: Spring clamp connection (4-core),
optionally RJ-45 socket
COMpact 5000R: RJ-45 socket
S
0
to-Point connection, EURO-ISDN (DSS1), unit is powered
locally
Max. 150 m with typical telephone or network cable (twisted-pair
Switchable; factory settings on
COMpact 5000: Spring clamp connection (2-core),
optionally RJ-45 socket
COMpact 5000R: RJ-45 socket
Tone dialling
Configurable: 0 to +12 dB
Important Information
basis access as Point-to-Multipoint connection, EURO-ISDN
with Euro-ISDN protocol (DSS1); 2 B-channels per port,
P0
basis access as Point-to-Multipoint connection or as a Point-
telephone or to the U
P0
/S adapter
0
65
