1. Safety guidelines
Safety requirements are detailed in further sections of this User Manual. Please
also observe the following requirements.
1.
Disconnect power supply and makes sure no voltage is present at the
terminals and cables before installation, repairs, maintenance and wiring.
2.
Dangerous voltage may be present at the terminals of the controller
switched off with a keypad.
3.
Do not misuse.
4.
The controller is intended for flush mounting.
5.
Use additional devices to protect the boiler, central heating system and
domestic hot water system against controller or software failure.
6.
The programmed parameters must correspond to the boiler type and fuel
type and allow for the system conditions. Incorrect parameters may result
in boiler failure (overheating, flashback to the fuel feeder etc.).
7.
The controller is intended for boiler manufacturers. Before using the
controller, the boiler manufacturer should verify if the controller is
compatible with the boiler type and does not cause hazard.
8.
The controller is not intrinsically safe, i.e. it may be a source of sparking
or high temperature at failure, which may cause fire or explosion of
flammable dusts or gases. Keep the controller clean.
9.
The controller must be installed by the boiler manufacturer in accordance
with relevant standards and regulations.
10. The parameters can be modified by authorized person only.
11. The controller may only be used in heating systems installed
in accordance with relevant regulations.
12. The controller wiring must be protected by a suitably rated fuse.
13. Do not use the controller with damaged enclosure.
14. Do not modify the controller in any way.
15. The controller is fitted with an electronic disconnector (type 2Y as per
PN-EN 60730-1) and micro-disconnector (type 2B as per PN-EN 60730-1).
16. Keep out of reach of children.
2. General information
The controller is a device for controlling an operation of a boiler with an
automatic solid fuel feeder and an igniter. The flame is detected by an optical
flame brightness detector. The controller may be used in a domestic hot water
circuit and a controlled heating circuit (mixing valve based), upon installation of
the additional B module.
The heating circuit temperature can be set based on the weather compensator
signal, and the compatibility with room thermostats allows to maintain comfort
temperature in heated rooms.
The device may also activate an auxiliary gas or oil boiler. The controller can
be coupled with ecoSTER TOUCH room temperature controller and ecoNET300
internet module. The controller can also be operated on-line via a website www.
econet24.com or a mobile app. The controller is intended for use in households
and light industrial sites..
Leader in pellet boilers
3. Manual information
This User Manual is part of the boiler documentation. Please follow instructions
provided in the boiler documentation. This manual contains two sections inten-
ded for a user and an installer. Both sections contain relevant safety information
and should both be read by the user. The manufacturer is not liable for any
damage due to the failure to follow instructions in this User Manual.
4. Storing documents
Please keep this User Manual and other relevant documents for future reference.
If moving or selling the controller, hand over the documentation to new user
or owner.
5. Symbols and designations
The following symbols and designations are used in this User Manual:
useful information and guidance,
important information which may affect property,
health or life of people and livestock,
CAUTION: symbols indicate useful information to facilitate use of this manual.
However, it does not release the user and the installer from following instruc-
tions not indicated with symbols!
6. WEEE Directive 2002/96/WE
Regulations on electrical and electronic equipment:
•
Dispose of the packaging and product after decommissioning
in an authorized recycling centre.
•
Do not dispose of the product with normal household waste.
•
Do not incinerate the product.
ecoMAX860P3-S – Simple Controller User Manual – EN 12.17
