Assembly and disassembly instructions

4 Assembly and disassembly instructions
10/2017
At least two fitters are required for the disassembly and assembly.
4.1

Tools and equipment

DANGER!
Infections can be spread by skin contact!
– Always wear safety gloves when working on a mas-
sage unit that has already been commissioned, as it
is always possible that you will come into contact with
the water that is being used (e.g. when changing the
drive belt or the rubber mat).
– You must use a disinfectant afterwards to clean your
hands, e.g. Skinman Soft SMS 50.
The following tools are required for disassembly and assembly:

No. 2 Philips screwdriver
 No. 3 Philips screwdriver
 8 to 19 mm double open-ended wrenches

4, 5 and 6 mm Allen keys
 Water pump pliers or 46 and 55 mm open-ended wrenches
 Torque Wrench (15720612) 8 mm (nut)

Ratchet wrench with PHZ-bit 2 and size 7, 8, 10 and 13 mm box span-
ners

Battery-powered screwdriver
 Size 4 (5/32") flat-bladed screwdriver
 Spirit level (at least 800 mm long)

½" water hose with Gardena hose-piece
 Industrial safety gloves
4.2

Scope of delivery

4.2.1

Supplied accessories


Technical documentation (folder with instructions, brochures for error
codes and additional documentation)
 Service card 12668-..
 Headrest 801091-..

Pressure hose 90906-.. (10 m, 3/8");
Inlet: 1.5 MPa (15 bar) operating pressure
 Hose 50909-.. (10 m, 1/2"); outlet
Installation instructions 15/68
